TIP-ON BLUMOTION Latch Set for Blum MERIVOBOX Runners
Designed for use with Blum MERIVOBOX 40kg and 70kg runners, this TIP-ON BLUMOTION latch set combines push-to-open convenience with smooth, soft-closing action — all mechanical, with no need for electrics.
Compatible with drawer lengths from 270mm to 650mm, it supports a range of load capacities using a simple colour-coded system. The latch unit ensures effortless, reliable opening with a light touch and silent, controlled closure for handle-less furniture.
The system includes 4-dimensional adjustment, including depth via a tool-free adjustment wheel, to ensure a precise, consistent gap layout.
for MERIVOBOX runners
Nominal length: 270-650mm
Trigger path: 1mm
Material: Nylon/steel
Fixing method: to slip-on
Depth adjustment: +/-2.5mm
Item package: right+left
| Nominal length | Weight range | Unit | Colour coding system |
|---|---|---|---|
| 270-300mm | ≤ 10kg 10-20kg |
S0 S1 |
White Light grey |
| 350-650mm | ≤ 20kg 15-40kg 35-70kg |
L1 L3 L5 |
Light grey Dust grey Black |
Recommended Weight Ranges (total weight of the pull-out) for an optimum opening and closing function.
Set Comprises:
1 x TIP-ON BLUMOTION unit left/right
1 x TIP-ON BLUMOTION latch left/right
2 x TIP-ON BLUMOTION synchronisation adapter
