91M2550 - MODUL Hinge: Slide-On with Screw-Fix Feature.
Discover the dependable and cost-effective concealed 91M2550 MODUL overlay hinge, tried and true through the test of time. Its slide-on mechanism simplifies front-to-cabinet assembly, with the integrated pull-out stop providing an added layer of safety, preventing accidental door detachments during assembly or adjustment. Additionally, the hinge's 3-dimensional adjustment ensures each door achieves a precise gap alignment.
Door thickness: 16 to 24mm
Opening angle: 100°
Boss assembly: Screw-on
Required fixings: Ø3.5 x 15mm Screws
Hinge material: Steel/Nickel plated
Closing mechanism: Spring-assisted
Installation instructions: Click here
Three-dimensional adjustment: +/-2mm side | +/-2mm depth | height via mounting plates
Note: Mounting plates required to be purchased separately View selection here
