78Z5500T - AVENTOS HF top bi-fold hinge set with 134 degree CLIP top centre hinge. Designed for HF top lift systems with wooden or wide aluminium frame fronts. Includes unsprung hinges and mounting plates for secure installation. Provides safe operation with anti-trap hinge design. Supplied as a complete hinge set.
Opening angle: 134°
Boss assembly: Screw-on
Boss material: Zinc boss
Closing mechanism: Unsprung
Side adjustment: +/- 2mm
Depth adjustment: + 1.5/- 3mm with spiral screw
Set comprises:
2 x CLIP top 120° unsprung hinge
2 x CLIP top centre unsprung hinge
6 x Horizontal cam mounting plate 175H3100
To find out more information and the entire range: Catalogue and technical manual
